Condenser Evaporative Condenser Steel Nice Bundy Tube For Air
Cooled Condenser Refrigerator
Description:
Color Bundy Tube /Single Wall Bundy Tube/Coating Bundy Tube
Diameter Size: 4,4.2,4.76,6.35,6.75,7.8,7.96,9.52,12.7
TK :0.5-1.0mm
Specifications:
Single wall bundy tube for condenser
Outer diameter: 4.0mm-12.0mm.
Wall thickness: 0.5mm-1.0mm.
Single wall bundy tube for Condenser .
Widely used in freezer,refrigerator
1. Material:be made of steel strap,low carbon;
2. Main use:widely used in refrigeration,freezer etc;
3. Outer diameter:4.00mm,4.76mm,6.00mm,6.35mm,8.00mm;
4. Wall thickness:0.50mm,0.60mm,0.65mm,0.70mm;
5. Packing as customer's request;
6. Also passed ISO9001 quality attestation system;
7. Competitive price among the same area.
8. Features: No stain, smooth surface, high intensity, good
plasticity, strong corrosion resistance, small resistance.
9. Package : wooden boxes,iron pallets,iron boxes etc,we also can
follow customer's own request
| Standard | ISO/TS16949 (Stricter than ASTM A254 and SAE J527) |
| Out Diameter | 4.76mm 6mm 6.35mm 8mm 10mm 12mm 14mm 15mm |
| Wall Thickness | 0.7 mm or 1 mm |
| Length | Cut to length, Any length as your requirements |
| Material | Low Carbon Steel/BHG2 |
| Usage | For automobile and refrigeration industry |
| Surface Treatment | Galvanization; colored zinc; PVF coated ; PAA coated ; nylon
coating tube |
| Certificate | ISO /TS 16949:2009 |
Bundy Tube /Brake Tube/ Coating Bundy Tube / PVF tube / Color Bundy
Tube / Single Wall Bundy Tube
Plating:Copper, White&Yellow Zinc, Olive Green and PVF
Size:4.76, 6.35, 8, 9.5*0.7 mm,etc.
ISO9001,TS16949
The low carbon steel brake tube is supplied in single wall and
double wall(Bundy Pipe). The products conform to ASTM A-254-91,
A-512-91A and ASTM A214 and A513 in material and quality. Commonly
sizes we supply to the client include 4.76mm×0.7 mm,6.35 mm×0.7 mm
and 8 mm×0.7 mm.
Plating:Yellow Zinc,White Zinc,Copper and PVE. Package:in
coils/cut-to-length Application:Hydraulic brake line tubing, brake
tubing, brake pipes, fuel lines, transmission oil cooler lines, air
conditioning tube, power steering, condenser, compressor,
evaporator etc.
Standard ASTM A254
OD:4mm,4.76mm 6mm 6.35mm.7.94mm,8mm,12.76
WT:0.4-1.0MM
